OPTEEQ Sensor Module

Sensor Module

ChannelThe four channels are completely independent, and different channels can program different chips at the same time
NetworkSupport 100 / 1000M Ethernet connection
Power Supply12V DC independent power supply
Interface ProtocolSupports multiple protocols such as SICI / SENT / SPC / PSI5 / PWM / BIPHASE / MANCHESTER
Dynamic Memory1GB large capacity onboard dynamic memory
StorageSupport 256G SD card
Dimension164mm x 161mm x 30mm, compact and easy to be integrated
Weight505 g
Signal Output Connector24 PIN, 2 ROW, PITCH=2.54 mm
Expandable UART Interface4 PIN, 1 ROW, PITCH=1.5 mm
Operating Temperature-40~85℃
